  • No. 405
  • 12,1 m 4,1 m 6,3 m
  • 15,6 x 7,1 m
  • from 5 to 14
  • 2,0 m
  • 1,0 m

  • necessary access for heavy construction machines

  • the equipment has a certificate in accordance with the standard, issued by the competent certification body

DESCRIPTION

The main structural element is the tower, made of square steel pipes with sides of 100 mm, which are protected against corrosion by hot-dip galvanizing. The foundations are made as reinforced concrete footings founded at a depth of 1 m. Access to the device is provided by two entrances: a tunnel and a side entrance. The tube slide is made of polyethylene. The beginning of the launching section is located at a height of 3.6 m. The tower enclosure is made of 10 mm thick HPL panels. Communication between levels is provided by a rope crossing. Polypropylene ropes reinforced with galvanized steel strings were used. The diameter of the rope is 16 mm. The elements connecting the ropes to each other are made of plastic and aluminum. The elements connecting the ropes to the pole are made of stainless steel.
The fall area of the equipment should be made on a surface in accordance with PN EN 1176- 1:2017. The possibility of access by heavy construction equipment is required for the installation.

DOWNLOADS
Product card
Download
DWG file
Download
